Inverted Flare Tube Fittings

Leaks and cracked lines cost you time. Inverted flare tube fittings lock up tight with a 2-piece 45° flare seal that handles vibration and up to 2,000 psi in brakes, power steering, fuel, or trans cooler lines. Choose elbows to turn, unions to extend, tees to branch, plugs to cap. Kimball Midwest keeps them ready.

51 results

Inverted Flare Male Connectors

Inverted Flare Female Connectors

Inverted Flare 45° Male Elbows

Inverted Flare 90° Male Elbows

Inverted Flare Unions

Inverted Flare Union Tees

Inverted Flare Female Branch Tees

Inverted Flare Brass Tube Nuts

Inverted Flare Steel Tube Nuts

Inverted Flare Steel Plugs

Inverted Flare Male Connectors

Inverted flare male connectors made from CA360 brass with a two-piece flare sealing method. Designed for hydraulic brake, power steering, fuel and gas lines and compatible with copper, brass, aluminum and steel tubing. Up to 2,000 psi and -65 °F to 250 °F operating range.

Tube OD: 1/8"

Male Pipe Size	Thread Size	Material	Shape	Maximum Pressure	Package Qty	Item #	Price Want to view pricing for this product? Log In or Create Login Not a Kimball Midwest Customer? Register
1/8"	5/16"-28	CA360 Brass	Male Connector	2,000 psi	10	202X2	Log in to view price
1/8" x 1/8" Inverted Flare Male Connector - 10 Pack Item #: 202X2 Package Weight: 0.3 lbs View Product Details Log in to Order

Tube OD: 3/16"

Male Pipe Size	Thread Size	Material	Shape	Maximum Pressure	Package Qty	Item #	Price Want to view pricing for this product? Log In or Create Login Not a Kimball Midwest Customer? Register
1/8"	3/8"-24	CA360 Brass	Male Connector	2,000 psi	10	202X3	Log in to view price
3/16" x 1/8" Inverted Flare Male Connector - 10 Pack Item #: 202X3 Package Weight: 0.3 lbs View Product Details Log in to Order

Tube OD: 1/4"

Male Pipe Size	Thread Size	Material	Shape	Maximum Pressure	Package Qty	Item #	Price Want to view pricing for this product? Log In or Create Login Not a Kimball Midwest Customer? Register
1/8"	7/16"-24	CA360 Brass	Male Connector	2,000 psi	10	202X4	Log in to view price
1/4" x 1/8" Inverted Flare Male Connector - 10 Pack Item #: 202X4 Package Weight: 0.3 lbs View Product Details Log in to Order
1/4"	7/16"-24	CA360 Brass	Male Connector	2,000 psi	10	202X4X4	Log in to view price
1/4" x 1/4" Inverted Flare Male Connector - 10 Pack Item #: 202X4X4 Package Weight: 0.4 lbs View Product Details Log in to Order

Tube OD: 5/16"

Male Pipe Size	Thread Size	Material	Shape	Maximum Pressure	Package Qty	Item #	Price Want to view pricing for this product? Log In or Create Login Not a Kimball Midwest Customer? Register
1/8"	1/2"-20	CA360 Brass	Male Connector	2,000 psi	10	202X5	Log in to view price
5/16" x 1/8" Inverted Flare Male Connector - 10 Pack Item #: 202X5 Package Weight: 0.4 lbs View Product Details Log in to Order
1/4"	1/2"-20	CA360 Brass	Male Connector	2,000 psi	10	202X5X4	Log in to view price
5/16" x 1/4" Inverted Flare Male Connector - 10 Pack Item #: 202X5X4 Package Weight: 0.5 lbs View Product Details Log in to Order

Tube OD: 3/8"

Male Pipe Size	Thread Size	Material	Shape	Maximum Pressure	Package Qty	Item #	Price Want to view pricing for this product? Log In or Create Login Not a Kimball Midwest Customer? Register
1/8"	5/8"-18	CA360 Brass	Male Connector	2,000 psi	10	202X6X2	Log in to view price
3/8" x 1/8" Inverted Flare Male Connector - 10 Pack Item #: 202X6X2 Package Weight: 0.4 lbs View Product Details Log in to Order
1/4"	5/8"-18	CA360 Brass	Male Connector	2,000 psi	10	202X6	Log in to view price
3/8" x 1/4" Inverted Flare Male Connector - 10 Pack Item #: 202X6 Package Weight: 0.7 lbs View Product Details Log in to Order
3/8"	5/8"-18	CA360 Brass	Male Connector	2,000 psi	5	202X6X6	Log in to view price
3/8" x 3/8" Inverted Flare Male Connector - 5 Pack Item #: 202X6X6 Package Weight: 0.4 lbs View Product Details Log in to Order

Tube OD: 1/2"

Male Pipe Size	Thread Size	Material	Shape	Maximum Pressure	Package Qty	Item #	Price Want to view pricing for this product? Log In or Create Login Not a Kimball Midwest Customer? Register
1/4"	3/4"-18	CA360 Brass	Male Connector	2,000 psi	5	202X8X4	Log in to view price
1/2" x 1/4" Inverted Flare Male Connector - 5 Pack Item #: 202X8X4 Package Weight: 0.3 lbs View Product Details Log in to Order
3/8"	3/4"-18	CA360 Brass	Male Connector	2,000 psi	5	202X8	Log in to view price
1/2" x 3/8" Inverted Flare Male Connector - 5 Pack Item #: 202X8 Package Weight: 0.4 lbs View Product Details Log in to Order

Tube OD: 3/4"

Male Pipe Size	Thread Size	Material	Shape	Maximum Pressure	Package Qty	Item #	Price Want to view pricing for this product? Log In or Create Login Not a Kimball Midwest Customer? Register
3/4"	1-1/16"-16	CA360 Brass	Male Connector	2,000 psi	2	202X12	Log in to view price
3/4" x 3/4" Inverted Flare Male Connector - 2 Pack Item #: 202X12 Package Weight: 0.5 lbs View Product Details Log in to Order

Inverted Flare Female Connectors

Inverted flare female connectors for flared hydraulic tubing made from CA360 brass. These two-piece flare fittings feature standard threads and female pipe ends, resist vibration and operate from -65 °F to 250 °F, provide up to 2,000 psi pressure capability, and suit brake, fuel and gas lines.

Tube OD	Female Pipe Size	Thread Size	Material	Shape	Maximum Pressure	Package Qty	Item #	Price Want to view pricing for this product? Log In or Create Login Not a Kimball Midwest Customer? Register
3/16"	1/8"	3/8"-24	CA360 Brass	Female Connector	2,000 psi	10	252X3	Log in to view price
3/16" x 1/8" Inverted Flare Female Connector - 10 Pack Item #: 252X3 Package Weight: 0.3 lbs View Product Details Log in to Order
5/16"	1/8"	1/2"-20	CA360 Brass	Female Connector	2,000 psi	10	252X5	Log in to view price
5/16" x 1/8" Inverted Flare Female Connector - 10 Pack Item #: 252X5 Package Weight: 0.4 lbs View Product Details Log in to Order

Inverted Flare 45° Male Elbows

Inverted flare 45° male elbows in CA360 brass for hydraulic and fuel tubing. Two-piece flare sealing provides reliable vibration resistance and up to 2,000 psi service at -65 °F to 250 °F. Used with copper, brass, aluminum and steel flared tubing for repair and equipment lines.

Tube OD: 3/16"

Male Pipe Size	Thread Size	Material	Shape	Maximum Pressure	Package Qty	Item #	Price Want to view pricing for this product? Log In or Create Login Not a Kimball Midwest Customer? Register
1/8"	3/8"-24	CA360 Brass	45° Elbow	2,000 psi	5	352X3	Log in to view price
3/16" x 1/8" MPT Inverted Flare 45° Male Elbow - 5 Pack Item #: 352X3 Package Weight: 0.1 lbs View Product Details Log in to Order

Tube OD: 1/4"

Male Pipe Size	Thread Size	Material	Shape	Maximum Pressure	Package Qty	Item #	Price Want to view pricing for this product? Log In or Create Login Not a Kimball Midwest Customer? Register
1/8"	7/16"-24	CA360 Brass	45° Elbow	2,000 psi	10	352X4	Log in to view price
1/4" x 1/8" MPT Inverted Flare 45° Male Elbow - 10 Pack Item #: 352X4 Package Weight: 0.4 lbs View Product Details Log in to Order

Tube OD: 5/16"

Male Pipe Size	Thread Size	Material	Shape	Maximum Pressure	Package Qty	Item #	Price Want to view pricing for this product? Log In or Create Login Not a Kimball Midwest Customer? Register
1/8"	1/2"-20	CA360 Brass	45° Elbow	2,000 psi	10	352X5	Log in to view price
5/16" x 1/8" MPT Inverted Flare 45° Male Elbow - 10 Pack Item #: 352X5 Package Weight: 0.4 lbs View Product Details Log in to Order
1/4"	1/2"-20	CA360 Brass	45° Elbow	2,000 psi	5	352X5X4	Log in to view price
5/16" x 1/4" MPT Inverted Flare 45° Male Elbow - 5 Pack Item #: 352X5X4 Package Weight: 0.3 lbs View Product Details Log in to Order

Tube OD: 3/8"

Male Pipe Size	Thread Size	Material	Shape	Maximum Pressure	Package Qty	Item #	Price Want to view pricing for this product? Log In or Create Login Not a Kimball Midwest Customer? Register
1/4"	5/8"-18	CA360 Brass	45° Elbow	2,000 psi	5	352X6	Log in to view price
3/8" x 3/8" MPT Inverted Flare 45° Male Elbow - 5 Pack Item #: 352X6 Package Weight: 0.5 lbs View Product Details Log in to Order

Inverted Flare 90° Male Elbows

Inverted flare 90° male elbows made from CA360 brass for use with copper, brass, aluminum and steel flared tubing. Two-piece flare sealing provides reliable leak resistance and excellent vibration performance. Suited for hydraulic, fuel and transmission lines in equipment maintenance.

Tube OD: 3/16"

Male Pipe Size	Thread Size	Material	Shape	Maximum Pressure	Package Qty	Item #	Price Want to view pricing for this product? Log In or Create Login Not a Kimball Midwest Customer? Register
1/8"	3/8"-24	CA360 Brass	Male Elbow	2,000 psi	10	402X3	Log in to view price
3/16" x 1/8" Inverted Flare 90° Male Elbow - 10 Pack Item #: 402X3 Package Weight: 0.3 lbs View Product Details Log in to Order

Tube OD: 1/4"

Male Pipe Size	Thread Size	Material	Shape	Maximum Pressure	Package Qty	Item #	Price Want to view pricing for this product? Log In or Create Login Not a Kimball Midwest Customer? Register
1/8"	7/16"-24	CA360 Brass	Male Elbow	2,000 psi	10	402X4	Log in to view price
1/4" x 1/8" Inverted Flare 90° Male Elbow - 10 Pack Item #: 402X4 Package Weight: 0.6 lbs View Product Details Log in to Order
1/4"	7/16"-24	CA360 Brass	Male Elbow	2,000 psi	5	402X4X4	Log in to view price
1/4" x 1/4" Inverted Flare 90° Male Elbow - 5 Pack Item #: 402X4X4 Package Weight: 0.3 lbs View Product Details Log in to Order

Tube OD: 5/16"

Male Pipe Size	Thread Size	Material	Shape	Maximum Pressure	Package Qty	Item #	Price Want to view pricing for this product? Log In or Create Login Not a Kimball Midwest Customer? Register
1/8"	1/2"-20	CA360 Brass	Male Elbow	2,000 psi	10	402X5	Log in to view price
5/16" x 1/8" Inverted Flare 90° Male Elbow - 10 Pack Item #: 402X5 Package Weight: 0.5 lbs View Product Details Log in to Order
1/4"	1/2"-20	CA360 Brass	Male Elbow	2,000 psi	10	402X5X4	Log in to view price
5/16" x 1/4" Inverted Flare 90° Male Elbow - 10 Pack Item #: 402X5X4 Package Weight: 0.8 lbs View Product Details Log in to Order

Tube OD: 3/8"

Male Pipe Size	Thread Size	Material	Shape	Maximum Pressure	Package Qty	Item #	Price Want to view pricing for this product? Log In or Create Login Not a Kimball Midwest Customer? Register
1/8"	5/8"-18	CA360 Brass	Male Elbow	2,000 psi	5	402X6X2	Log in to view price
3/8" x 1/8" Inverted Flare 90° Male Elbow - 5 Pack Item #: 402X6X2 Package Weight: 0.9 lbs View Product Details Log in to Order
1/4"	5/8"-18	CA360 Brass	Male Elbow	2,000 psi	10	402X6	Log in to view price
3/8" x 1/4" Inverted Flare 90° Male Elbow - 10 Pack Item #: 402X6 Package Weight: 1.1 lbs View Product Details Log in to Order
3/8"	5/8"-18	CA360 Brass	Male Elbow	2,000 psi	5	402X6X6	Log in to view price
3/8" x 3/8" Inverted Flare 90° Male Elbow - 5 Pack Item #: 402X6X6 Package Weight: 0.6 lbs View Product Details Log in to Order

Tube OD: 1/2"

Male Pipe Size	Thread Size	Material	Shape	Maximum Pressure	Package Qty	Item #	Price Want to view pricing for this product? Log In or Create Login Not a Kimball Midwest Customer? Register
3/8"	3/4"-18	CA360 Brass	Male Elbow	2,000 psi	5	402X8	Log in to view price
1/2" x 3/8" Inverted Flare 90° Male Elbow - 5 Pack Item #: 402X8 Package Weight: 1 lbs View Product Details Log in to Order
1/2"	3/4"-18	CA360 Brass	Male Elbow	2,000 psi	1	402X8X8	Log in to view price
1/2" x 1/2" Inverted Flare 90° Male Elbow Item #: 402X8X8 Package Weight: 0.3 lbs View Product Details Log in to Order

Inverted Flare Unions

Inverted flare unions made from CA360 brass for hydraulic and fuel tubing. Two-piece flare sealing provides reliable pressure handling to 2,000 psi and excellent vibration resistance. Suitable for copper, brass, aluminum and steel tubing in repair and equipment maintenance.

Tube OD	Thread Size	Material	Shape	Maximum Pressure	Package Qty	Item #	Price Want to view pricing for this product? Log In or Create Login Not a Kimball Midwest Customer? Register
1/8"	5/16"-28	CA360 Brass	Union	2,000 psi	10	302X2	Log in to view price
1/8" Inverted Flare Union - 10 Pack Item #: 302X2 Package Weight: 0.2 lbs View Product Details Log in to Order
3/16"	3/8"-24	CA360 Brass	Union	2,000 psi	10	302X3	Log in to view price
3/16" Inverted Flare Union - 10 Pack Item #: 302X3 Package Weight: 0.3 lbs View Product Details Log in to Order
1/4"	7/16"-24	CA360 Brass	Union	2,000 psi	10	302X4	Log in to view price
1/4" Inverted Flare Union - 10 Pack Item #: 302X4 Package Weight: 0.3 lbs View Product Details Log in to Order
5/16"	1/2"-20	CA360 Brass	Union	2,000 psi	10	302X5	Log in to view price
5/16" Inverted Flare Union - 10 Pack Item #: 302X5 Package Weight: 0.4 lbs View Product Details Log in to Order
3/8"	5/8"-18	CA360 Brass	Union	2,000 psi	10	302X6	Log in to view price
3/8" Inverted Flare Union - 10 Pack Item #: 302X6 Package Weight: 0.7 lbs View Product Details Log in to Order
1/2"	3/4"-18	CA360 Brass	Union	2,000 psi	10	302X8	Log in to view price
1/2" Inverted Flare Union - 10 Pack Item #: 302X8 Package Weight: 1.1 lbs View Product Details Log in to Order

Inverted Flare Union Tees

Inverted flare union tee made from CA360 brass for use with flared copper, brass, aluminum or steel tubing. Uses a two-piece flare sealing method and 3/8"-24 threads. Rated to 2,000 psi and -65 °F to 250 °F, provides excellent vibration resistance for hydraulic and fuel lines.

Tube OD	Thread Size	Material	Shape	Maximum Pressure	Package Qty	Item #	Price Want to view pricing for this product? Log In or Create Login Not a Kimball Midwest Customer? Register
3/16"	3/8"-24	CA360 Brass	Tee	2,000 psi	5	702X3	Log in to view price
3/16" Inverted Flare Union Tee - 5 Pack Item #: 702X3 Package Weight: 0.4 lbs View Product Details Log in to Order

Inverted Flare Female Branch Tees

Inverted flare female branch tee made from CA360 brass for hydraulic and fuel line applications. Two-piece flare sealing and 3/8"-24 threads provide reliable sealing up to 2,000 psi and -65 °F to 250 °F service. Excellent vibration resistance helps reduce leak risk.

Tube OD	Female Pipe Size	Thread Size	Material	Shape	Maximum Pressure	Package Qty	Item #	Price Want to view pricing for this product? Log In or Create Login Not a Kimball Midwest Customer? Register
3/16"	1/8"	3/8"-24	CA360 Brass	Branch Tee	2,000 psi	5	652X3	Log in to view price
3/16" x 1/8" Inverted Flare Female Branch Tee - 5 Pack Item #: 652X3 Package Weight: 0.3 lbs View Product Details Log in to Order

Inverted Flare Brass Tube Nuts

Inverted flare brass tube nuts made from CA360 brass for use with flared copper, brass, aluminum or steel tubing. These 2-piece flare nuts resist vibration and handle pressures up to 2,000 psi with a temperature range of -65 °F to +250 °F, providing reliable sealing for hydraulic and fuel lines.

Tube OD	Thread Size	Material	Shape	Maximum Pressure	Package Qty	Item #	Price Want to view pricing for this product? Log In or Create Login Not a Kimball Midwest Customer? Register
3/16"	3/8"-24	CA360 Brass	Nut	2,000 psi	25	100X3	Log in to view price
3/16" Inverted Flare Brass Tube Nut - 25 Pack Item #: 100X3 Package Weight: 0.3 lbs View Product Details Log in to Order
1/4"	7/16"-24	CA360 Brass	Nut	2,000 psi	10	100X4	Log in to view price
1/4" Inverted Flare Brass Tube Nut - 10 Pack Item #: 100X4 Package Weight: 0.2 lbs View Product Details Log in to Order
5/16"	1/2"-20	CA360 Brass	Nut	2,000 psi	10	100X5	Log in to view price
5/16" Inverted Flare Brass Tube Nut - 10 Pack Item #: 100X5 Package Weight: 0.2 lbs View Product Details Log in to Order
3/8"	5/8"-18	CA360 Brass	Nut	2,000 psi	10	100X6	Log in to view price
3/8" Inverted Flare Brass Tube Nut - 10 Pack Item #: 100X6 Package Weight: 0.4 lbs View Product Details Log in to Order

Inverted Flare Steel Tube Nuts

Inverted flare steel tube nuts for flared hydraulic tubing used on brake, power steering, fuel and transmission cooler lines. Steel construction with 2-piece flare sealing provides reliable vibration resistance and a pressure rating up to 2,000 psi. Suitable for industrial equipment maintenance.

Tube OD	Thread Size	Material	Shape	Maximum Pressure	Package Qty	Item #	Price Want to view pricing for this product? Log In or Create Login Not a Kimball Midwest Customer? Register
1/8"	5/16"-28	Steel	Nut	2,000 psi	25	105X2	Log in to view price
1/8" Inverted Flare Steel Tube Nut - 25 Pack Item #: 105X2 Package Weight: 0.2 lbs View Product Details Log in to Order
3/16"	3/8"-24	Steel	Nut	2,000 psi	25	105X3	Log in to view price
3/16" Inverted Flare Steel Tube Nut - 25 Pack Item #: 105X3 Package Weight: 0.3 lbs View Product Details Log in to Order
1/4"	7/16"-24	Steel	Nut	2,000 psi	10	105X4	Log in to view price
1/4" Inverted Flare Steel Tube Nut - 10 Pack Item #: 105X4 Package Weight: 0.1 lbs View Product Details Log in to Order
5/16"	1/2"-20	Steel	Nut	2,000 psi	10	105X5	Log in to view price
5/16" Inverted Flare Steel Tube Nut - 10 Pack Item #: 105X5 Package Weight: 0.2 lbs View Product Details Log in to Order
3/8"	5/8"-18	Steel	Nut	2,000 psi	10	105X6	Log in to view price
3/8" Inverted Flare Steel Tube Nut - 10 Pack Item #: 105X6 Package Weight: 0.3 lbs View Product Details Log in to Order
1/2"	3/4"-18	Steel	Nut	2,000 psi	10	105X8	Log in to view price
1/2" Inverted Flare Steel Tube Nut - 10 Pack Item #: 105X8 Package Weight: 0.5 lbs View Product Details Log in to Order

Inverted Flare Steel Plugs

Inverted flare steel plugs for hydraulic and fuel tubing. Steel construction with two-piece flare sealing that resists vibration and seals up to 2,000 psi. Rated -65 °F to 250 °F which helps maintain pressure integrity in brake, steering and fuel line applications.

Tube OD	Thread Size	Material	Shape	Maximum Pressure	Package Qty	Item #	Price Want to view pricing for this product? Log In or Create Login Not a Kimball Midwest Customer? Register
3/16"	3/8"-24	Steel	Plug	2,000 psi	10	131X3	Log in to view price
3/16" Inverted Flare Steel Plug - 10 Pack Item #: 131X3 Package Weight: 0.1 lbs View Product Details Log in to Order
1/4"	7/16"-24	Steel	Plug	2,000 psi	10	131X4	Log in to view price
1/4" Inverted Flare Steel Plug - 10 Pack Item #: 131X4 Package Weight: 0.2 lbs View Product Details Log in to Order
5/16"	1/2"-20	Steel	Plug	2,000 psi	10	131X5	Log in to view price
5/16" Inverted Flare Steel Plug - 10 Pack Item #: 131X5 Package Weight: 0.3 lbs View Product Details Log in to Order
3/8"	5/8"-18	Steel	Plug	2,000 psi	10	131X6	Log in to view price
3/8" Inverted Flare Steel Plug - 10 Pack Item #: 131X6 Package Weight: 0.4 lbs View Product Details Log in to Order
